Description
Meet the IP Audio 1 – your gateway to a world of unparalleled audio excellence! Boasting a high-powered, single-zone amplifier, this cutting-edge Host has built-in Savant Music streaming and convenient control ports for local equipment. Elevate your Savant IP Audio project by seamlessly adding an extra zone of premium audio quality.
But that’s not all – the IP Audio 1 takes your listening experience to new heights with enhanced DSP capabilities and embedded speaker profiles explicitly designed for Savant & Artison Speakers. Immerse yourself in the ultimate audio journey. Elevate your space with the IP Audio 1 – where innovation meets sound perfection!
KEY FEATURES
- Has Host capabilities
- Enables 2 zones of audio switching: 1 zone of amplification at 125 watts per channel and 1 zone of pre-amp output (RCA)
- DSP presets for Savant speakers
- 2 Audio inputs (1 analog, 1 digital) for distributing local audio sources
- Built-in stream of Savant Music 2.0
- Local control options (3 IR, 2 RS232)
- Can be installed surface mount with included hardware; optional rack-mount bracket available (RMB-SIPA12F-00)
- Savant Essentials subscription license enables premium features.
SPECS
Environmental:
- Temperature – 32° to 104° F (0° to 40°C)
- Humidity – 10% to 90% (non-condensing)
Control Ports:
- IR – 3 IR Control Ports
- Serial – 2 3-Pin RS232 Ports
Dimensions and Weights:
- Height – 1.70 in (4.34 cm)
- Width – 7.89 in (20.04 cm)
- Depth – 7.68 in (19.50 cm)
- Net Weight – 3.5 lbs (1.59 kg)
- Shipping Weight – 5.6 lbs (2.54 kg)
- Rack Space – 1U; 2 units can be placed side-by-side in a standard 19” NEMA rack.
Power:
- Input – 100/240V AC (50/60 Hz) 3.6A
- Maximum – 414W
- Operating Parameters:
- Rated Power (Speaker Output) – 125 WPC at 4/8 ohms (THD+N < 0.1%)
- Frequency Response – 20 Hz to 20 kHz (± 0.5 dB), speaker output
- Signal-to-Noise Ratio – (SNR) >100 dB, speaker output
- Supported Digital Input Format – 44.1 kHz / 48 kHz / 96 kHz / 192 kHz
Software
- Ships with Savant OS – da Vinci 10
