IP Audio 1 With Integrated Host And Savant Music 2.0

Introducing our cutting-edge Savant built-in host home automation system – meticulously crafted for residences seeking seamless control over up to four rooms of audio excellence. Elevate your living experience with the luxury of full automation in two rooms, managing everything from lighting and climate to shades and security. Transform your home into a haven of comfort and sophistication. Upgrade today to experience the epitome of intelligent living.

Brand:
SKU: HST-SIPA1SM-00 Category:

Description

Meet the IP Audio 1 – your gateway to a world of unparalleled audio excellence! Boasting a high-powered, single-zone amplifier, this cutting-edge Host has built-in Savant Music streaming and convenient control ports for local equipment. Elevate your Savant IP Audio project by seamlessly adding an extra zone of premium audio quality.

But that’s not all – the IP Audio 1 takes your listening experience to new heights with enhanced DSP capabilities and embedded speaker profiles explicitly designed for Savant & Artison Speakers. Immerse yourself in the ultimate audio journey. Elevate your space with the IP Audio 1 – where innovation meets sound perfection!

KEY FEATURES

  • Has Host capabilities
  • Enables 2 zones of audio switching: 1 zone of amplification at 125 watts per channel and 1 zone of pre-amp output (RCA)
  • DSP presets for Savant speakers
  • 2 Audio inputs (1 analog, 1 digital) for distributing local audio sources
  • Built-in stream of Savant Music 2.0
  • Local control options (3 IR, 2 RS232)
  • Can be installed surface mount with included hardware; optional rack-mount bracket available (RMB-SIPA12F-00)
  • Savant Essentials subscription license enables premium features.

SPECS

Environmental:
  • Temperature – 32° to 104° F (0° to 40°C)
  • Humidity – 10% to 90% (non-condensing)
Control Ports:
  • IR – 3 IR Control Ports
  • Serial – 2 3-Pin RS232 Ports
Dimensions and Weights:
  • Height – 1.70 in (4.34 cm)
  • Width – 7.89 in (20.04 cm)
  • Depth – 7.68 in (19.50 cm)
  • Net Weight – 3.5 lbs (1.59 kg)
  • Shipping Weight – 5.6 lbs (2.54 kg)
  • Rack Space – 1U; 2 units can be placed side-by-side in a standard 19” NEMA rack.
Power:
  • Input – 100/240V AC (50/60 Hz) 3.6A
  • Maximum – 414W
  • Operating Parameters:
  • Rated Power (Speaker Output) – 125 WPC at 4/8 ohms (THD+N < 0.1%)
  • Frequency Response – 20 Hz to 20 kHz (± 0.5 dB), speaker output
  • Signal-to-Noise Ratio – (SNR) >100 dB, speaker output
  • Supported Digital Input Format – 44.1 kHz / 48 kHz / 96 kHz / 192 kHz
Software
  • Ships with Savant OS – da Vinci 10
